Product Introduction
The FY-XS580D is a compact ride-on scrubber-dryer built for large hard floors. A 580 mm disc brush scrubs while an 830 mm squeegee lifts the dirty water in the same pass, so
nothing gets mopped twice and the aisle doesn't have to close. It's rated at 3,500 m²/h,carries 88 L of clean water and 100 L of dirty water, and runs on 24 V batteries. One seated operator, no cable, 1,400 mm long. OEM and ODM available.
Main Features
• 580 mm disc brush on a 550 W motor. Gets through dried-on grime on PVC, epoxy, concrete, terrazzo, tile and marble.
• Rated 3,500 m²/h, so one seated operator covers a few thousand square metres in a shift.
• Washes and dries in the same pass. The 830 mm squeegee follows right behind the brush, which means the floor is walk-safe by the time you've driven past it.
• 88 L of clean water, 100 L of dirty water. Longer runs between stops.
• Runs on 24 V batteries with no cable across the floor. Battery and charger are matched to how many hours a day you need it.
• Small for a rider: 1,400 × 830 × 1,250 mm, 156 kg net, so you can move it between sites without arranging special transport.
Key Specifications
| Item | Parameter |
|---|---|
| Model | FY-XS580D |
| Voltage | 24V |
| Cleaning Width | 580mm |
| Squeegee Suction Width | 830mm |
| Cleaning Efficiency | 3500 m²/h |
| Vacuum Motor | 500W |
| Brush Motor | 550W |
| Drive Power | 480W |
| Fresh Water Tank | 88L |
| Waste Water Tank | 100L |
| Net Weight | 156kg |
| Overall Dimension | 1400*830*1250 mm |
* Dimensions are measured by hand. Slight deviation is possible; the actual product prevails.
Product Advantages
1.Compact & Easy to Maneuver
Small single-brush body, simple steering wheel control. It can easily get into narrow aisles and tight corners where large scrubbers cannot go. Operators learn to use it quickly, no extensive training needed.
2.High Cleaning Output
Covers up to 3500 m² per hour. The 830mm rear squeegee pulls up wastewater completely, leaving floors dry right after cleaning. This removes slip risks and lets the area go back into use quickly.
3.Large Separate Water Tanks
88L clean water tank + 100L waste water tank. Longer continuous run time, less downtime for refilling and draining. Wide tank openings make regular cleaning simple and prevent odour buildup.
4.Reliable Power Setup
24V working system with matched brush, vacuum and drive motors. Consistent power for daily heavy use. The strong vacuum maintains good water pickup even on slightly uneven floors.
5.Low Maintenance & Versatile
Solid chassis and corrosion-resistant tanks for long service life. Wear parts like squeegee blades and brushes are easy to swap out. Safe to use on most common hard floor materials without surface damage.
Application Fields
1.Factories & Warehouses Great for production workshops, assembly zones and storage areas. It cleans concrete, epoxy and terrazzo floors, removing workshop dust, metal powder and light oil residues. It handles the constant dirt buildup typical in manufacturing spaces and keeps the facility compliant with site hygiene rules.
2.Underground Parking Garages Works well for basement parking lots. It removes tire marks, road dust, sediment and minor oil spills left by vehicles. The instant-dry result stops standing water in damp underground areas, cutting slip hazards for both pedestrians and cars.
3.Shopping Malls & Supermarkets Built for high foot-traffic retail spaces. Cleans marble, ceramic tile and PVC floors to wipe away footprints, drink spills and surface dust. Fast cleaning with no streaks keeps the store looking clean and improves customer experience.
4.Schools, Stations & Public Venues Suitable for school hallways, activity rooms, train and bus terminals. It handles large open public areas efficiently, cutting down heavy manual cleaning work. Dry floors reduce fall risks for students and visitors.
5.Hotels & Office Buildings Ideal for hotel lobbies, corridors and office common areas. It delivers streak-free cleaning to maintain a neat, professional look for hospitality and corporate spaces.
6.Gas Stations, Exhibition Halls & Gyms Handles mixed-use spaces including fuel stations, event halls and fitness centers. It reliably cleans oil spots, dust and ground sediment under varied working conditions.
7.Parking Garages Parking lots have tough stains including tire rubber marks, oil drips and road dust. The strong brush pressure and powerful suction cut through these deposits, improving the appearance of underground and outdoor parking structures.
Product Summary
The FY-XS580D ride-on floor scrubber is a practical cleaning solution for businesses looking to cut labor costs and improve cleaning results. It balances compact size, solid power and low maintenance, making it suitable for factories, parking garages, retail and public buildings. Instead of slow mop work, this machine cleans and dries floors in one step. It is a cost-effective choice for routine hard floor maintenance across many commercial and industrial sites.
